Studer OnAir 3000 User Manual

OnAir Digital Mixing Consoles
6-130 Conguration
Document generated: 10.10.14
SW V6.0
Function Assignable to: Details
Rel.
in
SW
Key Group Key Unit LED Display Display Module Rotary Unit
MonSrcRotary3rdHPDisplay V4.0 ●
Display function, shows either the selected rotary
source or the selected 3rdHP source depends on the
MonSrcSetHPSource function
MonSrcRotary3rdHPDisplay_CR
/ _S1
V4.0 ●
MonSrcRotary3rdHPActive V4.0 ●
DisplayMode function, is used to dim the display of the
MonSrcRotary3rdHPDisplay function
MonSrcRotary3rdHPActive_CR
/ _S1
V4.0 ●
MonSrcRotaryDisplay V4.0 ● Display function, shows the selected rotary source
MonSrcRotaryDisplay_CR / _S1 V4.0 ●
MonSrcRotaryActive V4.0 ●
DisplayMode function, is used to dim the display of the
MonSrcRotaryDisplay function
MonSrcRotaryActive_CR / _S1 V4.0 ●
MonSrcSetHPSource V4.0 ●
assign the 3rdHPSource selector to the MonSrcRotary
control, key in momentary mode
MonSrcSetHPSource_CR / _S1 V4.0 ●
MonSrcSetHPSource_ON V4.0 ●
assign the 3rdHPSource selector to the MonSrcRotary
control, key can only switch on
MonSrcSetHPSource_CR_ON
/ _S1_ON
V4.0 ●
MonSrcSetHPSource_OFF V4.0 ●
remove the 3rdHPSource selector from the
MonSrcRotary control
MonSrcSetHPSource_CR_OFF
/ _S1_OFF
V4.0 ●
MonSrcSetHPSource_LO V4.0 ●
assign the 3rdHPSource selector to the MonSrcRotary
control, key in latching mode
MonSrcSetHPSource_CR_LO
/ _S1_LO
V4.0 ●
5.1 functions only for CR and S1
MonNearField V2.2 ●
MonNearFieldVol V2.2 ●
MonNearFieldPanActive V6.0 ●
MonSurExtDownmixOff V2.2 ●
MonSurExtDownmixOn V2.2 ●
MonSurFormat51 V2.2 ●
MonSurFormatStereo V2.2 ●
MonSurLSP_Center V2.2 ● switch on/off the corresponding LSP, illuminate if on
MonSurLSP_Left V2.2 ● switch on/off the corresponding LSP, illuminate if on
MonSurLSP_LeftSur V2.2 ● switch on/off the corresponding LSP, illuminate if on
MonSurLSP_LFE V2.2 ● switch on/off the corresponding LSP, illuminate if on
MonSurLSP_Right V2.2 ● switch on/off the corresponding LSP, illuminate if on
MonSurLSP_RightSur V2.2 ● switch on/off the corresponding LSP, illuminate if on
MonSurLSPCut_Center V5.0 ● switch on/off the corresponding LSP, illuminate if off
MonSurLSPCut_Left V5.0 ● switch on/off the corresponding LSP, illuminate if off
MonSurLSPCut_LeftSur V5.0 ● switch on/off the corresponding LSP, illuminate if off
MonSurLSPCut_LFE V5.0 ● switch on/off the corresponding LSP, illuminate if off
