Common Operations
4
Executing Functions Corresponding to the Front Panel Keys of the DL750/DL750P
The functions corresponding to the front panel keys of the DL750/DL750P are assigned
to the keys on the USB keyboard. By pressing the keys on the keyboard, you can
operate the DL750/DL750P in a similar fashion. The assignment of functions varies
depending on the keyboard type. For details, see appendix 8.
Entering Values Directly from a USB Keyboard
You can directly enter values from a USB keyboard for items with or icon on the
DL750/DL750P menu.
Press the soft key corresponding to the item, enter the value from the
USB keyboard, and press the Enter key. The entered value is applied.
When you enter a value from
the USB keyboard, the entered
value appears in the black area.
Black area
• When a Prefix Unit Is Displayed
For voltage (V) and time (s) items, you can also enter the prefix unit from the USB
keyboard.
Example
Entering “1” “0” “m” for “Offset” is equivalent to entering “10 mV,” and the screen
displays “0.01 V.” If you enter the prefix unit from a USB keyboard, you do not have
to press the “Enter” key.
Below are the prefix units that can be entered.
Input Key Prefix Unit
K or k 10
3
(kilo)
m10
–3
(milli)
U or u 10
–6
(micro)
N or n 10
–9
(nano)
P or p 10
–12
(pico)
• When Displayed in Exponential Notation
You can also enter the menu items displayed in exponential notation from the USB
keyboard.
Example
Entering “2”, “.”, “3”, “E”, “1”, “Enter” for the menu item displaying “0.0000E+00”
causes the value to be displayed as “2.3000E+01”.
4.3 USB Keyboard/USB Mouse
