1-2
IM 701210-05E
1.1 Top Panel, Front Panel, Right Side Panel, and Left Side Panel
Front Panel
DL750
FILE
SHIFT
HELP
MISC
NUM KEY
PROTECT
VOICE
MEMO
SAVE
PRINT
ESC
MEASURE
CURSOR RESET SELECT
CH
ALL CH
MODE
POSITION
SIMPLE/ENHANCED
ACQ
START/STOP
SETUP DISPLAY
ZOOM
DUAL
CAPTURE
HISTORY
MATH
1
CH
2
CH
3
CH
4
CH
5
CH
6
CH
7
CH
8
CH
9
CH
10
CH
11
CH
12
CH
13
CH
14
CH
15
CH
16
DELAYACTION
MANUAL TRIG
SNAPSHOT CLEAR TRACE
MENU MENU
V/DIV TIME/DIV
TRIGGER
TRIG D
VERTICAL
HORIZONTAL
CAL
X-Y
SEARCH
GO/NO-GO
7
DSP 1
8 9
DSP 2
654
1
0
23
ENTER
m
DSP 6DSP 5
LOGIC A
LOGIC B
EVENT
DSP 3 DSP 4
EXP
LCD
For a description of the
displayed information,
see chapter 8.
ESC key
Used to clear the soft key menu and pop-up menu.
PROTECT key
Soft keys
Used to select items on the soft key menu
that appears when setting up the DL750.
Setup and execution
keys/knob
See page 1-7
for a description.
Setup and execution keys
See page 1-9 for a description.
Probe compensation signal
output terminal (1 kHz/1 V
P-P
)
Functional ground terminal
Connect the ground cable when
compensating the probe.
Outputs the probe compensation
signal.
For the probe compensation
procedure, see section 3.7.
Locks the keys. See section 17.6.
Jog shuttle
Used to change
settings and move
the cursor. Turn the
shuttle ring to
change the amount
of change according
to its angle.
DL750P
The name and function of each part are the same as the DL750.
