19.4 Display
Item Specifications
Display 10.4" color TFT LCD monitor
Display screen size 211.2 × 158.4 mm
Display resolution
1
SVGA 800×600 dots
Display resolution of the 650×512 (normal waveform display) or 750×512 (wide waveform display) selectable
waveform display
Display format Windows: Zoom: MAIN/MAIN&Z1/MAIN&Z2/MAIN&Z1&Z2/Z1only/Z2only Z1&Z2
X-Y: TY/XY/TY&XY
Maximum display update 30 times/s when a single waveform is displayed
rate
1. Liquid crystal display may include few defective pixels.(Within 5 ppm (6 points) of the total number of pixels (including RGB)
The LCD is a high technology device made up of more than 1.44 million pixels There may be pixels that do not turn ON or
those that remain ON at all times. However, these cases are not malfunction.
19.5 Function
Acquisition and Display
Item Specifications
Acquisition mode Normal: Normal waveform acquisition
Envelope: Maximum sampling rate regardless of the T/div setting, holds the peak value
Averaging: Average count 2 to 65536 (2
n
steps)
Box average: Increase the A/D resolution up to 4 bits (16 bits max.)
Record length 1 kW, 2.5 kW, 5 kW, 10 kW, 25 kW, 50 kW, 100 kW, 250 kW, 500 kW, 1 MW, 2.5 MW, 5 MW, 10
MW, 25 MW, 50 MW, 100 MW (/M1, /M2, or /M3 option), 250 MW (/M1, /M2, or /M3 option), 500
MW (/M2 or /M3 option), 1000 MW (/M3 option)
Zoom Expand the displayed waveform along the time axis (up two locations using separate zoom rates)
Display format 1, 2, 3, 4, 8, 16 analog waveform windows
Display interpolation Display samples using dot display, sine interpolation, or linear interpolation.
Graticule Select from three graticule types.
Auxiliary display ON/OFF Turn ON/OFF scale values, waveform labels, extra window, level indicator/numeric display.
X-Y display Select the X axis and Y axis from CH1 to CH16, DSP1 to DSP6, MATH1 to MATH8 (up to 4)
Accumulation Accumulates waveforms on the display (persistence mode)
Snapshot Retains the current displayed waveform on the screen. Snapshot waveforms can be saved and
loaded.
Clear trace Clears the displayed waveform.
Dual capture Performs data acquisition on the same waveform at two different sampling rates.
Main waveform Maximum sample rate: 100 kHz (roll mode region)
(low speed) Maximum memory length: 100 MW
Sub waveform Maximum sample rate: 10 MS/s
(high speed) Maximum memory length: 10 kW (fixed)
Realtime hard disk Maximum sample rate: 100 kS/s (for 1 CH) max.
recording Capacity: Up to 1 GW per operation
Action count: Select Single or Continue.
If Continue is selected, set the count in the range of 2 to 128.
Features: Restore process not required. Saved to a format that can be loaded
directly.
Voice memo Records a voice as a memo while waveforms are being acquired (when in roll mode display). The
recorded voice memo can be saved along with the waveform data. Maximum record time is 100 s.
Voice comment Saves screen image data by attaching a voice comment (separate data from screen image data).
The maximum length of voice comment that can be attached to a single screen image data is 10 s.
Plays the voice comment from the File List window.
