Part 1:xiii
IM 701210-05E
Functions Described in This Manual and the DL750/
DL750P Version
The contents of this manual describe the DL750/DL750P version 6.20 or later. The table
below shows the relationship between the DL750/DL750P versions and the new functions
and supported modules. If the DL750/DL750P is not of the newest version, you will not be
able to use all the functions covered in this manual. Check the DL750/DL750P version by
referring to Soft Version on the overview screen that appears by selecting the MISC key >
Overview soft key. For details on the procedure, see section 18.4 in the User’s Manual
Part 2. For up-to-date information about the DL750/DL750P versions and the procedure
for upgrading your DL750/DL750P, check the following Web page.
http://www.yokogawa.com/tm/DL750/
DL750/DL750P Versions and New Functions
Version Suffix New Functions Reference Page/
Code Section/Chapter
1.09 or later Standard • Voice memo and voice comment
Pages 2-36
and
2-64
,
sections 7.9
and
13.19
2.02 or later Standard • Wave window trigger
Page 2-26
and
section 6.17
• Cycle statistical processing
Page 2-57
and
section 11.7
• Chinese menu and message support
Section 17.1
/G3 • DSP channels
Page 2-50
,
chapter 15
, and
appendix 6
3.01 or later Standard • Numeric monitor display
Page 2-39
and
section 8.13
• Added exponential window to FFT computation/increased number
Page 2-47
,
section 10.5
,
of points in FFT computation (up to 100 kpoints).
page app-21
• Normal statistical processing/statistical processing of history memory
Page 2-57
and
section 11.7
• Increased the number of parameters for automated
Sections 11.6
and
11.7
measurement/statistical processing of waveform parameters
(Up to 24000 increased to up to 48000)
• Added waveform data save formats for action-on-trigger and
Pages 2-29
and
2-58
, and
GO/NO-GO determination (select from binary, ASCII, and floating)
Section 13.7
• Support for inverted display on the strain module
Page 2-14
and
section 5.12
• Support for current probe (701931)
Page 2-9
and
section 3.6
/G3 • Support for enhanced trigger (OR trigger and window trigger) on
Pages 2-22
and
2-26
,
DSP channels
chapter 15
• Knocking filter
Section 15.6
3.10 or later Standard • Added Korean to the menu languages. Added Korean, German,
Section 17.1
French, and Italian to message languages.
4.01 or later Standard • Changed the number of screens that can be captured on the dual
Page 2-34 and section 7.6
capture function
• Selection of the traces to be displayed on the dual capture function
section 7.6
•
Mail transmission using the dual capture trigger function
section 7.6
•
Automated measurement of waveform parameters on the dual
section 11.6
capture function
•
Added the action on stop function.
section 7.8
•
Parameter search of the history memory function
section 11.3
•
Added H&V cursor measurement to T-Y waveforms
section 11.5
Standard, /G3
•
Filter Hz display
Sections 10.5
and
15.3
/C10
•
SNTP function
Sections 3.5
and
16.8
•
WebDAV server function
Section 16.11
• Mail attachment function of image data
Section 16.5
/DC • Added the DC power supply option (DL750 only)
Section 3.4
4.02 or later Standard • START/STOP key response time
Section 7.1
5.01 or later Standard • Recording in recorder mode (DL750P only)
Chapter 9
• Connection of USB storage device to the USB PERIPHERAL interface
Section 13.3
(DL750P only)
• Creation of PDF files of the printed image (DL750P only)
Section 13.13
• Support for current probe (701933)
Page 2-9
and
section 3.6
• Added 16 divided windows to the display format
Section 8.1
• Added the output format to the built-in printer (Zoom Print) and
Section 12.2
changed the name of the function Long copy to Fine print
• Added the linear scaling display format
Section 5.11
6.01 or later Standard • Creation of PDF files of the reprint image in X-Y Recorder Mode
Section 9.9
(DL750P only)
• Creation of PDF files of the printed image (X-Y waveform) (DL750P only)
Section 13.3
Standard, /G2 • Overall value display of the power spectrum computation (FFT)
Section 10.13, 10.5, 11.6,
and page App-19
