Specifications
19
Item Specifications
Recording format T-Y waveform recording: 1 division recording 200 mm/zone or 160 mm/zone (flexible zone is
selectable for 1 division recording)
2 division recording 80 mm/zone or 100 mm/zone
3 division recording 60 mm/zone or 65 mm/zone
4 division recording 40 mm/zone or 50 mm/zone
8 division recording 20 mm/zone
16 division recording 10 mm/zone
Numeric value recording: Print direction selectable from standard and 180° rotation.
X-Y waveform recording: Records up to 4 waveforms simultaneously. Assignment of X and Y
channels on the 4 waveforms is arbitrary.
Graticule Width: Selectable from 1 div and 10 mm.
Type: Selectable from two types and OFF.
Density: Dark/Light selectable.
Recorded contents Simultaneously prints, scale, channel label, graticule, timestamp, gauge, annotation, etc.
During T-Y waveform recording
Scale: Prints the scale value for each channel. Select the print interval from OFF, 200,
400, and 800 mm.
Channel label: Prints channel labels near the waveforms. Select the print interval from OFF,
200, 400, and 800 mm.
Time print: Prints the recording start time and timestamps. Select the print interval from
OFF, 200, 400, and 800 mm.
Gauge: Prints the scale value for each channel and the end of printing.
Annotation: Select channel information, channel message, or Data to be printed.
Channel information: Prints information such as V/div, filter, etc.
Message: Prints a preset message string.
Data: Prints numeric measured values.
Select the print interval from OFF, 200, 400, and 800 mm.
During X-Y waveform recording Prints the scale value.
Shot recording Automatically stops when the specified length is recorded after the start of measurement or after the
trigger condition is met.
Shot recording length: Continuous, 20 cm, 50 cm, 1m, or 2 m
External start/stop Shared with the GO/NOGO start terminal. Prints on a low signal. Stops printing on a high signal.
Reprint function An arbitrary section of the recorded data saved to the memory simultaneously with realtime print
can be reprinted in an arbitrary format.
Print image output When performing reprint or fine print during T-Y waveform recording, the print image can be
converted and output to a PDF file.
Screen Image Data Output
Item Specifications
Built-in printer Outputs a hard copy of the screen
External printer Outputs the screen image to an external printer via the USB PERIPHERAL terminal or the Ethernet
network
1
.
Supports ESC-P, ESC-P2, LIPS3, PCL5, BJ commands, and PostScript (only via the Ethernet
network
1
)
Floppy disk, Zip disk, Output data format: PNG, JPEG, BMP, and PostScript
PC card, SCSI,
internal HDD (optional),
Network drive
1
1. When the Ethernet interface option is installed (against a printer server supporting TCP/IP)
Data Storage
Item Specifications
History memory Automatically holds up to 2000 pages of waveforms (depending on the memory length)
Floppy disk, Zip disk, Saves waveform data, setup data, and various data
PC card, SCSI,
internal HDD (optional),
Network drive
1
1. When the Ethernet interface option is installed
19.5 Function
