19-8
IM 701210-06E
Acquisition Memory Backup
Item Specifications
Batteries 4 AAA alkaline dry cells (AA/R6) (JIS, IEC model: LR6)
4 nickel hydride rechargeable batteries
Backup time Reference value for A1070EB (LR6JE CPT alkaline battery by Toshiba) × 4 at an ambient
(reference value) temperature of 23° C
On models with the /M3 option Approx. 10 h
On models with the /M2 option Approx. 15 h
On models with the /M1 option Approx. 32 h
On the standard model Approx. 150 h
Backup function Enable/Disable using the ON/OFF switch
Contents that are Acquisition memory waveform data (history memory data and sub waveform data of the dual
backed up capture function) and voice memo data
Other Functions
Item Specifications
Initialization Resets settings to the factory default (excluding date/time setting, communication interface settings,
SCSI ID number setting, language setting, time difference from the GMT, and the ON/OFF setting of
the internal hard disk motor)
Auto setup Automatically sets the voltage axis, time axis, trigger level, etc.
Action-on-trigger Outputs screen image data, saves waveform data, activates buzzer notification, or sends e-mail
messages each time a trigger occurs.
Mail transmission function
1
Sends the DL750/DL750P status periodically to a specified mail address via the Ethernet network.
Also sends information as an action for GO/NO-GO determination and action-on-trigger.
Calibration Auto calibration and manual calibration available
System settings Sets the screen color, date/time, message language, and click sound ON/OFF
Probe compensation Outputs a signal (rectangular signal of approx. 1 V
P-P
and approx. 1 kHz) from the probe
signal output compensation output terminal on the front panel
Overview Shows system specifications
Self test Memory test, key test, printer test, FDD/Zip drive/PC card drive test, internal HDD (optional) test,
and SCSI test
Help function Displays help concerning the settings (English/Japanese/Chinese switchable)
Thumbnail Shows thumbnails of the screen image data
PROTECT key Disables keys to prevent inadvertent errors in operation.
NUM key Direct input of numeric values.
1. When the Ethernet interface option is installed
19.6 Built-in Printer
Item Specifications
Printing system Thermal line dot system
Paper width DL750: 112 mm, DL750P: 210 mm
Effective printing width DL750: 104 mm (832 dots), DL750P: 204 mm (1632 dots)
Dot density 8 dots/mm
Feeding direction resolution DL750: For normal print: 13 dots/mm. For fine (long) print: 10 dots/mm
DL750P: For normal print: 8 dots/mm. For fine (long) print: 10 dots/mm
Function Normal print, fine print, zoom print, A4 print (DL750P only), realtime recording (DL750P only)
Maximum paper DL750: Approx. 10 mm/s during normal print (depends on the head temperature when normal
feeding speed printing is started and the print rate)
DL750P: 20 mm/s
19.5 Function/19.6 Built-in Printer
