16-51
IM 701210-06E
Ethernet Interface (Optional)
16
16.10 Setting the FTP Passive Mode and LPR/SMTP
Timeout
Procedure
MEASURE
CURSOR RESET SELECT
CH
ALL CH
MODE
POSITION
SIMPLE/ENHANCED
ACQ
START/STOP
SETUP DISPLAY
ZOOM
DUAL
CAPTURE
HISTORY
MATH
1
CH
2
CH
3
CH
4
CH
5
CH
6
CH
7
CH
8
CH
9
CH
10
CH
11
CH
12
CH
13
CH
14
CH
15
CH
16
DELAY
MANUAL TRIG
V/DIV TIME/DIV
TRIGGER
TRIG D
VERTICAL
HORIZONTAL
CAL
X-Y
SEARCH
7
DSP 1
8 9
DSP 2
654
1
0
23
ENTER
m
DSP 6DSP 5
LOGIC A
LOGIC B
EVENT
DSP 3 DSP 4
EXP
GO/NO-GO
ACTION
FILE
SHIFT
FILE
SHIFT
HELP
MISC
NUM KEY
1. Press MISC.
2. Press the Network soft key.
3. Press the Others soft key. The Others setup menu appears.
Selecting the FTP Passive Mode
4. Use the jog shuttle and SELECT to set FTP Passive to ON or OFF.
Setting the LPR Timeout Time
4. Use the jog shuttle and SELECT to set LPR Time Out.
Setting the SMTP Timeout Time
4. Use the jog shuttle and SELECT to set SMTP Time Out.
Explanation
Special settings related to the FTP client, LPR, and SMTP are entered. Normally, these
parameters do not need to be specified.
Turning ON/OFF FTP Passive Mode
Turn this function ON when using the DL750/DL750P behind a firewall that requires the
passive mode. The default setting is OFF. (A firewall is furnished on a system that has
security features. It prevents intrusion from the outside into the network system.)
Setting the LPR Time Out
The DL750/DL750P closes the connection to the printer if there is no response from the
printer for a certain period of time (timeout time) when it accesses the printer. You can
set the timeout value in the range of 0 to 3600 s. The default setting is 15 s.
Setting the SMTP Time Out
When a mail server is accessed from the DL750/DL750P and connection cannot be
established after a certain period of time (timeout time), the DL750/DL750P decides that
the connection to the mail server is not possible and closes the connection. You can set
the timeout value in the range of 0 to 3600 s. The default setting is 15 s.
To Next Page
