8.4 Accumulated Waveform Display

Procedure

MEASURE

CURSOR RESET SELECT

ALL CH

MODE

POSITION

SIMPLE/ENHANCED

ACQ

START/STOP

SETUP DISPLAY

ZOOM

DUAL

CAPTURE

HISTORY

MATH

DELAY

MANUAL TRIG

V/DIV TIME/DIV

TRIGGER

TRIG D

VERTICAL

HORIZONTAL

CAL

X-Y

DSP 1

8 9

DSP 2

654

ENTER

DSP 6DSP 5

LOGIC A

LOGIC B

EVENT

DSP 3 DSP 4

EXP

GO/NO-GO

ACTION

FILE

SHIFT

Setting the Accumulate Mode

1. Press DISPLAY.

2. Press the Accumulate soft key. The accumulate mode selection menu

appears.

3. Press the OFF or Persist soft key to select the accumulate mode.

If you select Persist, proceed to step 4.

Setting the Accumulate Time

4. Turn the jog shuttle to set the Count in the range of 2 to 128 (2

step).
