4.7 Using the Help Function

Procedure

FILE

SHIFT

HELP

MISC

NUM KEY

PROTECT

VOICE

MEMO


SAVE

SNAPSHOT CLEAR TRACE

MENU MENU

Displaying the Help Window

1. Press HELP.

2. Press the key or soft key that you wish to review.

Clearing the Help Window

3. Press HELP again.

Explanation

Displaying the Help Window

When you press HELP, a help window containing information about the soft key menu or

jog shuttle menu that was displayed immediately before HELP was pressed appears. A

help window does not open on some keys.

If you press a key while the help window is displayed, a help window containing

information about the key appears.

Clearing the Help Window

If you press HELP again while a help window is displayed, the help window closes.
