13-60
IM 701210-06E
13.16 Copying Files
CAUTION
Never remove the storage medium (disk) or turn OFF the power while the
access indicator or the floppy disk, Zip disk, internal hard disk (optional), or USB
storage device icon is blinking. Such acts can damage the storage medium or
destroy the data on the medium.
Procedure
MEASURE
CURSOR RESET SELECT
CH
ALL CH
MODE
POSITION
SIMPLE/ENHANCED
ACQ
START/STOP
SETUP DISPLAY
ZOOM
DUAL
CAPTURE
HISTORY
MATH
1
CH
2
CH
3
CH
4
CH
5
CH
6
CH
7
CH
8
CH
9
CH
10
CH
11
CH
12
CH
13
CH
14
CH
15
CH
16
DELAY
MANUAL TRIG
V/DIV TIME/DIV
TRIGGER
TRIG D
VERTICAL
HORIZONTAL
CAL
X-Y
SEARCH
7
DSP 1
8 9
DSP 2
654
1
0
23
ENTER
m
DSP 6DSP 5
LOGIC A
LOGIC B
EVENT
DSP 3 DSP 4
EXP
GO/NO-GO
ACTION
FILE
SHIFT
1. Press FILE.
2. Press the Utility soft key. The Utility setup menu and the File List window
appear.
3. Press the Function soft key. The file function selection menu is displayed.
4. Press the Copy soft key.
Selecting Media and Directories
5. Select the medium and directory according to steps 4 to 9 in section 13.8,
“Saving/Loading the Setup Data.”
Selecting the Copy Source Files One at a Time
6. Turn the jog shuttle to select the file.
7. Press the Set/Reset soft key. An asterisk (*) to the left of the selected file to
indicate that it will be copied. Pressing the Set/Reset soft key again removes
the asterisk (*) to the left of the selected file. The file will not be copied.
Proceed to step 11.
