App-9
IM 701210-06E
Appendix
App
Appendix 4 ASCII Header File Format
//YOKOGAWA ASCII FILE FORMAT
$PublicInfo
FormatVersion 1.11
Model DL750
Endian Big
DataFormat Trace
GroupNumber 4
TraceTotalNumber 13
DataOffset 111548
$Group1
TraceNumber 4
BlockNumber 1
TraceName CH1 CH2 CH3 CH4
BlockSize 10010 10010 10010 10010
VResolution 4.1666667E-04 2.0833333E-02 2.0833333E-02 2.0833333E-02
VOffset 1.0000000E+00 0.0000000E+00 0.0000000E+00 0.0000000E+00
VDataType IS2 IS2 IS2 IS2
VUnit ? V V V
VPlusOverData ? ? ? ?
VMinusOverData ? ? ? ?
VIllegalData -32768 -32768 -32768 -32768
VMaxData 32767 32767 32767 32767
VMinData -32767 -32767 -32767 -32767
HResolution 2.0000000E-04 2.0000000E-04 2.0000000E-04 2.0000000E-04
HOffset -2.0018000E+00 -2.0018000E+00 -2.0018000E+00 2.0018000E+00
HUnit s s s s
Date 2004/1/15 2004/1/15 2004/1/15 2004/1/15
Time 14:25:38.54 14:25:38.54 14:25:38.54 14:25:38.54
$Group2
TraceNumber 4
BlockNumber 1
TraceName CH5 CH6 CH7 CH8
BlockSize 10010 10010 10010 10010
VResolution 2.0833333E-03 2.0833333E-03 2.0833333E-03 2.0833333E-03
VOffset 0.0000000E+00 0.0000000E+00 0.0000000E+00 0.0000000E+00
VDataType IS2 IS2 IS2 IS2
VUnit V V V V
VPlusOverData ? ? ? ?
VMinusOverData ? ? ? ?
VIllegalData -32768 -32768 -32768 -32768
VMaxData 32767 32767 32767 32767
VMinData -32767 -32767 -32767 -32767
HResolution 2.0000000E-04 2.0000000E-04 2.0000000E-04 2.0000000E-04
