YOKOGAWA DL750 User Manual

App-46
IM 701210-06E
Appendix 7 List of Defaults
Key Soft Key Default Setting
CH1 to 16 (HS10M12 (701250))
V/div 50.0 V/div
Variable OFF
Position 0.00 div
Coupling DC
Probe 10:1
BandWidth Full
V Zoom ×1
Offset 0.0 V
Linear Scale OFF
Invert OFF
Label Channel number
CH1 to 16 (HS1M16 (701251))
V/div 50.00 V/div
Variable OFF
Position 0.00 div
Coupling DC
Probe 10:1
BandWidth Full
V Zoom ×1
Offset 0.00 V
Linear Scale OFF
Invert OFF
Label Channel number
CH1 to 16 (NONISO_10M12(701255))
V/div 50.0 V/div
Variable OFF
Position 0.00 div
Coupling DC
Probe 10:1
BandWidth Full
V Zoom ×1
Offset 0.0 V
Linear Scale OFF
Invert OFF
Label Channel number
CH1 to 16 (HV(with RMS)(701260))
V/div 5.000 V/div
Variable OFF
Position 0.00 div
Coupling DC
Probe 1:1
BandWidth Full
V Zoom ×1
Offset 0.000 V
Linear Scale OFF
Invert OFF
Label Channel number
CH1 to 16 (UNIVERSAL (701261)/UNIVERSAL (AAF)
(701262))
V/div 5.000 V/div
Variable OFF
Position 0.00 div
Coupling DC
BandWidth Full
V Zoom ×1
Offset 0.000 V
Linear Scale OFF
InVert OFF
Label Channel number
Key Soft Key Default Setting
CH1 to 16 (TEMP/HPV (701265))
V/div 5.000 V/div
Variable OFF
Position 0.00 div
Coupling DC
BandWidth Full
V Zoom ×1
Offset 0.000 V
Linear Scale OFF
Invert OFF
Label Channel number
CH1 to 16 (STRAIN_NDIS(701270)/
STRAIN_DSUB(701271))
Range Unit µSTR
Range 20000 µSTR
Upper 20000 µSTR
Lower -20000 µSTR
Excitation 2 V
Gauge Factor 2.00
BandWidth Full
Linear Scale OFF
Label Channel number
CH1 to 16 (ACCL/VOLT(701275))
V/div 50.00 V/div
Variable OFF
Position 0.00 div
Coupling DC
Probe 10:1
BandWidth Full
V Zoom ×1
Offset 0.00 V
Linear Scale OFF
Invert OFF
Label Channel number
CH1 to 16 (FREQ(701280))
V/div 1 kHz/div
Variable OFF
Position 0.00 div
FV Setup Frequency
Input Setup User
V Zoom ×1
Offset 0.000 Hz
Linear Scale OFF
Label Channel number
Logic A, Logic B
Display OFF
Position 0 div
VZoom ×1
Label LogicA or LogicB
Display Bits ON
Bit Label A–1 to A–8,
B–1 to B–8
Bit Mapping Auto
EVENT
Display OFF
Position 0 div
V Zoom ×1
Label Event
Display Bits ON
