App-47
IM 701210-06E
Appendix
App
Appendix 7 List of Defaults
Key Soft Key Default Setting
START/STOP
STOP
TIME/DIV
1 ms/div
ACQ
Record Length 10 k
Mode Normal
Count Infinite
RealTime Out OFF
Time Base Int
SIMPLE/ENHANCED
Type Simple
Slope Rising edge
Source CH1
Level 0 V
Hysteresis
Hold Off 0 µs
MODE
Auto
HISTORY
Select Record 0
Display Mode One
Start Record 0
End Record Oldest number
Search Mode OFF
MEASURE
Mode OFF
Item Setup:Trace CH1
Item Setup:Item OFF
Delay Setup:Trace CH1
Delay Setup:Mode OFF
1cycle Mode OFF
Time Range1 –5 div
Time Range2 5 div
Trace CH1
Dist/Prox Mode %
Distal 90%
Mesial 50%
Proximal 10%
High/Low Mode Auto
CURSOR
Type OFF
DISPLAY
Format Quad
Interpolation Line
Graticule Grid
Mapping Auto
Tranclucent OFF
Extra Window OFF
Scale Value ON
Trace Label OFF
Accumlate OFF
Monitor Both
X-Y
Mode T-Y
W1:XTrace
W1:YTrace
W2:XTrace
W2:YTrace
W3:XTrace
W3:YTrace
W4:XTrace
W4:YTrace
Start Point –5 div
End Point 5 div
Key Soft Key Default Setting
MATH
Mode OFF
Operation:Math1 OFF
Operation:Math2 OFF
Operation:Math3 OFF
Operation:Math4 OFF
Operation:Math5 OFF
Operation:Math6 OFF
Operation:Math7 OFF
Operation:Math8 OFF
Start Point –5 div
End Point 5 div
Threshold:Trace CH1
Threshold:Upper 0.0 V
Threshold:Lower 0.0 V
Average:Mode OFF
Phase Shift 0.000 msec
Filter:Select FILT1
Filter:Type Gauss
Filter:Band Low-Pass
Filter:CutOff 10.0%
FFT Point 1 k
FFT Window Hanning
Constant:K1 to K8 1.0000E+00
DSP1 to 6(optional)
Display OFF
Variable OFF
Position 0.0 div
Setup C1+C2
Value/Div 10.00E+00
V Zoom ×1
Label DSP Channel number
ZOOM
Mode Main
Format Main
Allocation 0 to 3 from 1CH
Z1 Mag 500 µs/div
Z2 Mag 500 µs/div
Z1 Position 0 div
Z2 Position 0 div
SEARCH
Type Edge
Result Window Z1
Setup:Source CH1
Setup:Level 0 V
Setup:Polarity Rising edge
Setup:Hysteresis
Setup:Count 1
Setup:Start Point –5 div
DUAL CAPTURE
Mode OFF
Time/Div 100 µs/div
Capture Num Current
Window OFF
Window Mag 100 µs/div
Window Pos 0 div
Event Display OFF
POSITION/DELAY
Position 50%
Delay 0.0 µs
