Page #254 background imageLoading...
Page #254 background image
6-36
IM 701210-05E
Explanation
The following four period triggers are available.
T > Time: A trigger is activated when condition B is met the second time, if the time
when condition B is met the second time is longer than a specified time.
T < Time: A trigger is activated when condition B is met the second time, if the time
when condition B is met the second time is shorter than a specified time.
T1 < T < T2: A trigger is activated when condition B is met the second time, if the time
when condition B is met the second time is within a specified time range.
T < T1, T2 < T: A trigger is activated when condition B is met the second time, if the time
when condition B is met the second time is outside a specified time
range.
Setting Condition B
Pattern of Each Channel: CH1 to CH16, Logic A, and Logic B
Select from the following:
CH1 to CH16 (Other Than Logic Inputs)
H: Above the preset trigger level
L: Below the preset trigger level
X: Don’t Care
Logic Input
Enable: Make the combination of the pattern
1
of each bit the trigger condition
Disable: Don’t Care
1. Select the pattern of each pattern from the following:
H: Above a certain level
2
L: Below a certain level
2
X: Don’t Care
2. Varies depending on the logic probe being used as follows:
700986: Approx. 1.4 V
700987: 6 V± 50% (for DC input)
700987: 50 V± 50% (for AC input)
Setting the Time of Satisfaction
For T > Time or T < Time
Time: 0.1 µs to 9999999.9 µs
For T1 < T < T2 or T < T1, T2 < T
Time1: 0.1 µs to 9999999.9 µs
Time2: 0.2 µs to 10000000.0 µs
Setting the Trigger Level
The trigger level setting applies to both simple and enhanced triggers.
For details, see “Setting the Trigger Level” in section 6.5.
Setting the Trigger Hysteresis
Sets a width to the trigger level so that triggers are not activated by small changes in the
trigger signal. Select the trigger hysteresis from
, , and .
For details, see “Setting the Trigger Hysteresis” in section 6.5.
6.15 Setting the Period Trigger (ENHANCED)
