Setting the Sub Waveform
• Record Length of the Sub Waveform
Fixed to 10 kW.
• Time/div Setting of the Sub Waveform
The maximum sample rate is 10 MS/s.
• Acquisition Mode of the Sub Waveform
Fixed to Normal.
• Trigger Setting of the Sub Waveform
When the dual capture mode is turned ON, the trigger setting is no longer applied to
the main waveform, but applied to the sub waveform.
In addition, the trigger output during acquisition in dual capture mode becomes the
trigger output of the sub waveform.
• Sub Waveform Display: Window
Select the from the following four types.
OFF: Does not display the sub waveform.
Right : Displays the sub waveform at the lower right section of the screen at 1/4 size.
Left: Displays the sub waveform at the lower left section of the screen at 1/4 size.
Full: Displays the sub waveform on a full screen.
• Waveform Display Position: Window Pos
Set the display position of the sub waveform.
• Sub Waveform Zoom Ratio: Window Mag
The sub waveform is displayed at the zoom rate specified by Window Mag around the
waveform display position specified by Window Pos.
• Display Format of Sub Waveforms
Set the display format of sub waveforms.
Main: Same format as the main window Single: 1 window
Dual: 2 windows Triad: 3 windows
Quad: 4 window Octal: 8 windows
Hexadecimal: 16 windows
Selecting the Displayed Trace: Allocation
The traces that are turned ON under Allocation are displayed.
• Displaying the Acquired Waveform: Capture Num
You can specify the number of the acquired waveform to be displayed in the sub
waveform window.
The time that is shown below the number is the trigger time of the waveform.
When in Auto Mode
Current, –1, –2, ....
where current is the newest waveform, –1 is the waveform previous to the newest
waveform, and –2 is the waveform that is 2 triggers before the newest waveform.
The acquired waveform can be displayed only when the waveform acquisition is
stopped.
When in Log Mode
Current, 1, 2, ....
where current is the newest waveform, 1 is the oldest waveform, and 2 is the second
oldest waveform.
The acquired waveform can be displayed even when the waveform acquisition is in
progress.
7.6 Using the Dual Capture Function
