8-11
IM 701210-05E
Display
8
Zoom Position: Z1Position and Z2Position
• The zoom position can be set by specifying the zoom center position (center of the
zoom box) in the range –5 to +5 divisions with the center of the waveform display
frame set to 0 divisions. The resolution is as follows:
Selectable steps of zoom position: T/div × 10 ÷ display record length
• The zoom box enclosed by solid lines is Z1 and the one enclosed by dashed lines is
Z2. Since each box is independent, you can set the position separately.
Changing the Range of the Automated Measurement of Waveform Parameters:
Fit Meas Range to Z1/Fit Meas Range to Z2
Sets the range of the automated measurement of waveform parameters to the zoom
range of Z1 or Z2. This is valid even if the automated measurement of waveform
parameters is turned OFF.
Moving the Zoom Box to the Head Position of Waveform: Z1 to Front/Z2 to Front
Moves the zoom box of Z1 or Z2 to the head position of the main waveform.
8.5 Zooming the Waveform
To Next Page
