9-5
IM 701210-05E
Recording in Recorder Mode (Realtime Recording) (Only on the DL750P)
9
Explanation
Selecting the Recorder Mode
When recording in recorder mode, first select the recorder mode. There are two
recorder modes, Chart Recorder and X-Y Recorder. If Chart Recorder mode is selected,
select the print style, Wave (record T-Y waveforms) or Numeric (record numeric values).
Functions That Cannot Be Used during Chart Recorder Mode or X-Y Recorder
Mode
The following functions (keys) cannot be used during recorder mode.
• History memory (HISTORY)
• GO/NO-GO determination (GO/NO-GO)
• Dual capture
• Waveform computation (MATH)
Also, items that are set with the ACQ or X-Y key cannot be changed.
Search & zoom (SHIFT+ZOOM (SEARCH)) cannot be used in X-Y Recorder mode.
DL750P Settings in Chart Recorder Mode
If Chart Recorder mode is selected, the DL750P settings change as follows:
Menu Soft Key Setting
ACQ Record Length Fixed to 2.5 MW
Mode Envelope
*1
Time Base Int
RealTime Out OFF
TIME/DIV Linked to the chart speed
*2
X-Y Mode T-Y Only
GO/NO-GO Mode OFF
MATH Mode OFF
DUAL CAPTURE Mode OFF
MEASURE Mode Statistics and History Statistics set to OFF
DISPLAY Accumulate OFF
*1 The acquisition mode can be changed from Envelope to Normal using MISC menu > Others
soft key. For details, see section 9.3.
*2 For the procedure of setting the chart speed, see section 9.3.
If the recorder mode is switched from OFF to Chart Recorder mode back to OFF, the
ACQ menu items and TIME/DIV setting return to the settings that existed before
switching to Chart Recorder mode.
DL750P Settings during X-Y Recorder Mode
If X-Y Recorder mode is selected, the DL750P settings change as follows:
Menu Soft Key Setting
ACQ Record Length Fixed to 1 MW
(TRIGGER)MODE Auto
If the recorder mode is switched from OFF to X-Y Recorder mode back to OFF, the ACQ
menu items and (TRIGGER) MODE setting return to the settings that existed before
switching to X-Y Recorder mode.
9.2 Selecting the Recorder Mode
To Next Page
