Recording in Recorder Mode (Realtime Recording) (Only on the DL750P)

9

Reprint Example of T-Y Waveform Recording

Gauge

Time T/div

Scale value

Scale value

V/div

(Value/div)

Arrow indicating

the ground

position

Channel label

Annotation (channel information)

Format: Triad

Graticule Type:

Width: 10 mm

Time Time

9.8 Reprinting on the Built-in Printer
