YOKOGAWA DL750 User Manual

1-11
IM 701210-05E
Names and Functions of Parts
1
Zoom Waveform Display
T/div of the normal
waveform display
(section 5.2)
Display position of the Z2 zoom waveform
with respect to the entire record length
Z1 zoom range
Display position of the Z1 zoom waveform
with respect to the entire record length
T/div of the Z2 zoom
waveform display
(section 8.5)
Normal waveform
display area
Zoom waveform
display area
T/div of the Z1 zoom waveform display (section 8.5)
Z1 zoom waveform
display area
Z2 zoom waveform
display area
Record length of the
Z1 zoon waveform
Record length of the
Z2 zoom waveform
Record length of the
normal waveform
Z2 zoom range
Dual Capture Display
T/div of the normal
waveform display
(section 5.2)
T/div of the sub
waveform display
(section 7.6)
Trigger position of
the sub waveform
Normal waveform
display area
Time from the
reference point
Zoom waveform
display area
Sub waveform display area
Date/Time when the main
waveform was stopped
Number of acquisitions
of the sub waveform
Scale value of the time axis of
the sub waveform
Date/Time of the
trigger point of
the sub waveform
Position of the sub waveform specified by Capture Num
with respect to the main waveform
Time reference
mark
1.3 Display Screens
