13-65
IM 701210-06E
Saving and Loading Data
13
Explanation
Selecting the Storage Medium and Directory: File List
Media on which saving and loading are possible are displayed on the File List window.
• Display Examples of Storage Media
[FD]: Floppy disk
[ZIP]: Zip disk
[PC Card]: PC card
[HD]: Hard disk
[SCSI5]: SCSI device with the ID number set to 5
1
[SCSI5-1]: Partition 1 of a CSI device whose ID number is 5
1
[NetWork]: Network drive when the Ethernet interface option is installed)
[USB]: USB storage device
1. When a SCSI device whose ID number is 5 is connected
Selecting the File Attribute: Attr (Excluding Net Drive)
Select the file attribute of each file from the following list of choices.
• R/W
Read and write possible.
•R
Read only. Cannot write to the file or delete the file.
Changing the Directory/File Name of the Storage Medium: Rename
Number of characters and types that can be used
Item Number of Characters Characters That Can Be Used
Directory name 1 to 16 characters 0 to 9, A to Z, %, _, (, ), -
File name 1 to 16 characters 0 to 9, A to Z, %, _, (, ), -
* However, a directory name that starts with “ND” (ND000 for example) is not allowed.
Creating a Directory: Make Dir
You can create a new directory in the medium. See above for the assignment of the
directory name when creating a new directory.
Specifying the File to Be Displayed on the File List Window: Filter
Specify the type of files to be displayed.
• *.Extension
Displays only the data file that was selected in the File Item setup menu and the data
type menu.
• *.*
Displays all the files in the medium.
13.17 Changing the Directory/File Name of the Storage Medium and Creating Directories
To Next Page
