16-13

IM 701210-06E

Ethernet Interface (Optional)

16.4 Setting up the Network Printer

Explanation

As with the built-in printer, you can print the screen image data on a network printer via

the Ethernet network.

Setting the Network Printer: Net Print Setup

• LPR Server

Specify the IP address of the network printer server. On networks supporting DNS,

you can specify the host and domain by name instead of the IP address.

• Printer Name: LPR Name

Specify the name of the printer on which screen image data will be printed.

Selecting the Output Format

The following six printer formats are supported.

• ESC-P

• ESC-P2

• LIPS3

• PCL5

•BJ

• PostScript
