16-21
IM 701210-06E
Ethernet Interface (Optional)
16
16.6 Accessing the DL750/DL750P from a PC or Workstation (FTP Server Function)
Executing the FTP Client Software
9. Execute an FTP client software on the PC or workstation. Perform file
operations using the user name specified in steps 4 and 5.
Displaying the Connection Log List
10. Press the Connect Log List soft key. The data and time, user name, and IP
address of the 25 recent accesses are displayed.
Note
• The log list is cleared when the power is turned OFF.
• The DL750/DL750P supports two clients, but file operations cannot be performed
simultaneously.
• When the DL750/DL750P is being accessed from a PC or workstation (logged in), is
displayed in the lower right part of the screen.
• This function cannot be used when using the FTP client function, network printer function,
or the Web server function, or when performing file operations.
• To use this function, configure the TCP/IP settings beforehand according to section 16.2,
“Setting the TCP/IP.”
• To apply new settings, the DL750/DL750P must be power cycled.
• The files that can be uploaded to the DL750/DL750P are those with the following
extensions.
.WVF, .HDR, and .SET
However, do not upload files to the realtime recording area.
