16-27
IM 701210-06E
Ethernet Interface (Optional)
16
16.7 Using the Web Server Function
Preparations on the PC
1. Power up the PC and log on.
If the PC is running Windows NT, Windows 2000, or Windows XP, log on as an
administrator. If you do not log on as an administrator, you may not be able to install files
that are required for using the Web server function (described later).
• Logging into the Web Server (DL750/DL750P)
2. Start Internet Explorer.
3. Enter the IP address of the DL750/DL750P (for example, 192.168.0.101) or the
host name of the DL750/DL750P (for example, dl750-1) if a DNS server is
available on the network.
Enter the IP address http://192.168.0.101/
Enter the host name http://dl750-1/
4. Press the ENTER key on the PC keyboard. A network password entry dialog
box opens.
5. Enter the user name and password.
• Enter the user account (see section 16.6) used to access the DL750/DL750P. In the
example below, “DLUSER” and “*****” are entered for the user name and password,
respectively.
• If the user name of the user account is set to “anonymous” (default setting), the
password is not required.
6. Click OK. If the login to the DL750/DL750P Web server is successful, the Web
server window appears.
Web Server Window
To Next Page
