19-11
IM 701210-06E
Specifications
19
Video Signal Output (VIDEO OUT (SVGA))
Item Specifications
Connector type 15-pin D-Sub receptacle
Output type Analog RGB output
Output resolution SVGA output 800 × 600 dots/60 Hz Vsync
GO/NO-GO Determination I/O (GO/NO-GO)
Item Specifications
Connector type Modular jack (RJ-11)
I/O level START IN input: TTL (0 to 5 V), SW input possible
GO-OUT/NOGO-OUT: CMOS (0 to 5 V)
Signal START IN, GO-OUT, and NOGO-OUT
Compatible cable Four-wire modular cable for telephone lines (GO/NO-GO cable (YOKOGAWA: 366973))
External Start/Stop
1
Item Specifications
Connector Shared with the GO/NO-GO start terminal (used exclusively). Can be used as start/stop input when
GO/NO-GO I/O is not used.
Input TTL (0 to 5 V) or switch input
Start on low, stop on high
Compatible cable Four-wire modular cable for telephone lines (GO/NO-GO cable (YOKOGAWA: 366973))
1. The terminal is also used as a GO/NO-GO Terminal.
COMP Output (Rectangular Signal Output for Probe Compensation)
Item Specifications
Output frequency 1 kHz±1%
Output amplitude 1 V±10%
Voice Input/Output (VOICE IN/OUT/SW)
1
Item Specification
Compatible earphone microphone
Earphone microphone with a PUSH switch (YOKOGAWA: 701951)
Dynamic inner earphone
Input impedance: 32 Ω
Frequency range: 100 to 20 kHz
Maximum input: 40 mW
Electric condenser microphone
Output impedance: 1.6 kΩ
Frequency characteristics: 100 to 10 kHz
Directional characteristics: Omnidirectional
Code: 1.2 m, φ2.5, with 4-pin plug
Weight: Approx. 16 g
Earphone microphone jack input/output
Jack: 4-pin jack
Microphone input: Electric condenser microphone, input impedance of approx. 5 kΩ
Earphone output: Dynamic, impedance of 32 Ω
Switch input: 10-kΩ pull-up (3.3 V)
1. The specifications above apply to the optional earphone microphone with a PUSH switch (701951) that is sold separately.
Operation of other earphone microphones are not guaranteed.
19.9 Auxiliary I/O Section
To Next Page
