Altera Corporation 13–5
July 2005 Stratix Device Handbook, Volume 2
Package Information for Stratix Devices
Figure 13–1 shows a package outline for the 484-pin FineLine BGA
packaging.
Figure 13–1. 484-Pin FineLine BGA Package Outline
D
A1
A3
A2
A
E
e
e
b
Pin A1 ID
Pin A1
Corner
BOTTOM VIEWTOP VIEW
