Package Information for Stratix Devices
Figure 13–6 shows a package outline for the 1,508-pin FineLine BGA
packaging.
Figure 13–6. 1,508-Pin FineLine BGA Package Outline
Pin A1
Corner
b
e
E
D
Pin A1 ID
A2
A3
A1
A
e
TOP VIEW BOTTOM VIEW
