3.4 LX800 Motherboard
The Dialog+ (software 9.xx) uses the LX800 motherboard. A compact flash card CFC is
connected to the motherboard. The BIOS is described in paragraph 3.3.5.
LVDS
(connector only, LVDS
adapter integrated on
LX800)
Power
Speaker
HDD
Hard Disk Drive
FDD
Floppy Disk Drive
USB2
COM1PS/2
COM2
(DIABUS)
COM3
(ABPM)
COM4
(Touch Screen)
USB1 Service
SW/FSU
re
d
(connector with
-
out code Pin)
Black
USB3
Type A
JWP Write Protect
Enable write protect
Disable write protect
2
1
3
2
JBAT CMOS
Normal CMOS
Clear CMOS
1
2
2
3
VGA
USB1
JLVDSPWR TFT Power
3.3 V: BoeHydis/Samsung
5 V: Philips
1
3 5
2
4 6
1
3
5
2
4
6
Black
9
7
5
3
1
9
7
5
3
1
LPT
(FPB)
JCFSET1
Setting CFC
5
3
1
6
4
2
USB8
USB7
USB6
USB5
USB4
Battery
(
3 V
)
