3. Repair Instructions 1/2010 3 - 91
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
3.6.10.5 Get Error (ErrorDisk)
The error files can only be analysed by qualified personnel of B. Braun
Avitum (e.g. development department) and should be provided only on
special request.
The utility gets error information and log files from Dialog+ hard disk drive
(CFC) and writes them to the USB stick. Files from different Dialog+ machines
are placed in different subdirectories on the USB stick (VFAT partition). The
subdirectory names
/USER/14_Get Error/<SERNUM>/<DATE>/
are created from
the serial numbers of the Dialog+ machines and from the current date of
reading
<DATE>
.
<SERNUM>
The subdirectory name is created from the serial number <SERNUM> of
the Dialog+. If the serial number is not set on the Dialog+ <SERNUM> is
equal to ‘-----‘.
<DATE>
The subdirectory name is created from a date. Format: YYYY-MM-
DD.hh.mm.ss.
In case of ERRDISK: the date is the date of the reading.
12_Read_All_Trends
BlueCat
Removable Disk (X: - FSU USB Stick)
DISKTYPE
USER
05_Write_Calibration_Data
04_Write_Languages
06_Write_System_Configuration
09_Card_01_Read_Card_Image
09_Card_02_Write_Card_Image
09_Card_03_Read_Patient_Diskette
09_Card_04_Write_Patient_Diskette_to_Card
09_Card_05_Read_Patient_Card
10_Read_System_Configuration
09_Card_06_Write_Patient_Card
11_Read_Calibration_Data
13_Read_Screenshots
14_Get_Error
23532
2007-08-30.15.34.12
ERR_INFO
LOG
See the results in the directories with the following path:
Get Error
USB:\USER\14_Get_Error\{Serial Number}\{YYYY-MM-
DD.hh.mm.ss}\ERR_INFO
Example:
USB:\USER\14_Get_Error\23532\2007-08-
30.15.34.12\ERR_INFO
23532: Serial Number of the Dialog machine
YYYY: Year 2007
MM : 08 month August
DD : 30 Thursday
hh : 15 hours
mm : 34 minutes
ss : 12 seconds
ERR_INFO: Error information
LOG: Log
