B. Braun Dialog+ - Alarm System

3. Repair Instructions 1/2010 3 - 11
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
3.3.5 Alarm System
Test Code
16
Repeats Until Error Message
1
ID Error Message
1167:
Sound + LED test failed
Actions after Error
None (test is repeated immediately)
LLC Test
Code
LLC Test Steps LLS Test Steps LLS Test
Code
Code LLC LLS Code
1.
Prerequisites for Test:
No alarm activation
2. Test code = 16 to LLS Test code = 16 back to LLC
3. 1610x
OSD LED OFF, Sound OFF
No alarm activation
Timeout 60 s
Start condition for the test:
1. „OSD-LED OFF“ detected
2. „Sound OFF“ detected
Activation of the red OSD LED
Wait for feedback of the activation and switch-off of
the LED
Wait for LED off
16001
16002
16003
16004
4. Acknowledge with switch-off of the power supply
trigger, i.e. switch-off of VGD and VGB
16005 –
16010
5. 1620x Wait for D24OFF and B24OFF (timeout 60 s since start
of code 100)
6. Trigger ON 16011
7. 1630x Wait for D24ON and B24ON (timeout 10 s)
8. 1630x
D24ON and B24ON:
Alarm activation LLC/TLC
Activation test alarm with sound and OSD LED red (ID
1002)
Condition for the test:
1. „OSD LED red left and right ON“ detected
2. „Sound ON“ detected
16021
9. Acknowledge with switch-off VGD 16022 –
16027
10. 1640x Wait for D24OFF (timeout 60 s since start of code 200)
11. VGD ON 16028
12. 1650x Wait for D24ON (timeout 10 s)
13. 1699 Completed
