B. Braun Dialog+ - Write Calibration Data

3. Repair Instructions 1/2010 3 - 66
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
3.6.7.2 Write Calibration Data
The utility writes the
Calibration Data
from the USB stick to the hard disk drive
(CFC) of the Dialog+ machine.
BlueCat
Removable Disk (X: - FSU USB Stick)
DISKTYPE
USER
05_Write_Calibration_Data
DEFAULT
04_Write_Languages
If calibration data are not on the FSU USB stick
The calibration data must be read to the USB stick with the
11
Read Calibration Data
utility, because by default the directory is
empty.
Write Calibration Data
USB:\USER\05_Write_Calibration_Data\DEFAULT\
calib.dat.xxu
Note:
The
Calibration Data
file can be copied back to the
Dialog+ machine only, if the serial number and main
version number, saved in the
Calibration Data
file, are
equal with the serial number and main version number
reported by the Dialog+ machine.
Write and Read Calibration Data
Write (download) the calibration data from the FSU USB stick to the same
Dialog+ machine only.
The calibration data should be saved to the
hard disk drive (CFC)
in the TSM
service program:
TSM Main Menu , File Operations , Save Calibration Data .
You should read (download) the calibration data from the respective
Dialog+ to the USB stick before you start servicing the machine with the
Read Calibration Data utility in the FSU menu.
The last write procedure can be undone with the
07 Undo Last Written
utility.
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
01. Set System Version Number
02. Set Working Time Counter (WTC)
03. Kill Masterboot Record (Dialog+ Hard Disk)
04. Write Languages (USB Stick
→
Dialog+ Hard Disk)
05. Write Calibration Data (USB Stick
→
Dialog+ Hard Disk)
06. Write System Configuration (USB Stick
→
Dialog+ Hard Disk)
07. Undo Last Written (USB Stick
→
Dialog+ Hard Disk)
08. USB Stick Self Test
09. Select Menu of Card Reader Commands
10. Read System Configuration (Dialog+ Hard Disk
→
USB Stick)
11. Read Calibration Data (Dialog+ Hard Disk
→
USB Stick)
12. Read All Trends (Dialog+ Hard Disk
→
USB Stick)
13. Read Screenshots (Dialog+ Hard Disk
→
USB Stick)
14. Get Error (ErrorDisk) (Dialog+ Hard Disk
→
USB Stick)
BP-
: move cursor up
BP+
: move cursor down
AQ
: exit – see
Important Note EQ
: execute
Important Note:
To prevent the corruption of USB stick, before removing it,
please press
AQ
then follow the instructions on the screen!
1.
Press
BP
and move the cursor down to select
the utility.
2.
Press
EQ
to execute the utility.
