4.5 Service Overview in TSM
Service Program
The service overview can be selected with the
key in the TSM service
program.
Required Data to LLC Actual Data from LLC
PUMP
BICP: X
BPA: X
BPV: X
EP: X
FPA: X
FPE: X
KP: X
UFP: X
HEATER
H: X
SAD
SAD_LEVEL: X
ACTIONS
LEAKTEST: ON/OFF
EMPTYING: ON/OFF
BL_LAMP_T: ON/OFF
SAD_TEST: ON/OFF
VALVE
RVE: X
VVBE: OPEN/CLOSED
VABK1: OPEN/CLOSED
VDABK1: OPEN/CLOSED
VEBK1: OPEN/CLOSED
VDEBK1: OPEN/CLOSED
VABK2: OPEN/CLOSED
VDABK2: OPEN/CLOSED
VEBK2: OPEN/CLOSED
VDEBK2: OPEN/CLOSED
VBP: OPEN/CLOSED
VDE: OPEN/CLOSED
VDA: OPEN/CLOSED
VD OPEN/CLOSED
VZ: OPEN/CLOSED
VLA: OPEN/CLOSED
VDFF: OPEN/CLOSED
VSB: OPEN/CLOSED
VBE OPEN/CLOSED
VSAE: OPEN/CLOSED
VSAA: OPEN/CLOSED
PUMP
BPA: X
BPAIMP_S: X
BPA_FLOW: X
BPA_COVER:OPEN/CLOSED
BPV: X
BPVIMP_S: X
BPV_COVER:OPEN/CLOSED
EP: X
FPE: X
FPA: X
UFP_S: X
UFP_FLOW: X.X
UFP_FLOW_S: X.X
BICP_S: X
BICP_FLOW: X.X
BICP_FLOW_S: X.X
KP_S: X
KP_FLOW: X.X
KP_FLOW_S: X.X
HP_POS: X.X
HPKOLB: ON/OFF
HPKRALLO: OPEN/CLOSED
PRESSURE
PA: X
PA_S: X
PV: X
PV_S: X
PBE: X
PBS: X
PBS_S: X
PDA: X
PDA_S: X
PE: X
LEVEL
NSVB: HIGH/LOW
LAFS: HIGH/MIDDLE/LOW
TEMPERATURE
TSE XX.X
TSHE XX.X
TSBIC XX.X
TSD XX.X
TSD_S XX.X
TSDE XX.X
VALVE
VBP_S: OPEN/CLOSED
BALANCE CHAMBER
MSBK1: XXXXX
MSBK2: XXXXX
VABK1_S: OPEN/CLOSED
VDABK1_S: OPEN/CLOSED
VEBK1_S: OPEN/CLOSED
VDEBK1_S: OPEN/CLOSED
VABK2_S: OPEN/CLOSED
VDABK2_S: OPEN/CLOSED
VEBK2_S: OPEN/CLOSED
VDEBK2_S: OPEN/CLOSED
COUPLINGS
BIC_SS: OPEN/CLOSED
K_SS: OPEN/CLOSED
SBS1: OPEN/CLOSED
SBS2: OPEN/CLOSED
BKUS OPEN/CLOSED
BKUS_S OPEN/CLOSED
CONDUCTIVITY
BICLF: X.XX
ENDLF X.XX
ENDLF_S X.XX
AUTOMATIC TEST & CALIBRATION
LF: X.XX PA: XXX
TSD: X.X PDA: XXX
TSE: X.X
WORKING TIME COUNTER
WTC: XXXXX
FREE MEMORY (Mb)
XXXX of XXXXXX kB S: XX/XX MB
BLOOD LEAK
BLCON: X.XXX
BLCON_S: X.XXX
SAD
SAD_LEVEL: XX
SAD_LEV_S: X.XXX
SAD: AIR/BLOOD
SAD_S: AIR/BLOOD
VDE_S: OPEN/CLOSED
VDA_S: OPEN/CLOSED
VD_S OPEN/CLOSED
VZ_S: OPEN/CLOSED
VLA_S: OPEN/CLOSED
VDFF_S: OPEN/CLOSED
VSB_S: OPEN/CLOSED
VBE_S: OPEN/CLOSED
VSAE_S: OPEN/CLOSED
VSAA_S: OPEN/CLOSED
STATUS
RDV: NO BLOOD/BLOOD
RDV_S NO BLOOD/BLOOD
POWER
B24VOFF: ON/OFF
D24VOFF: ON/OFF
LLC STATUS: 00000000 0000000 LLS STATUS: 00000000
Fig.: Service Overview in TSM Service Program
Balance Chamber
MSBK1: 32123
MSBK2: 32253
Digit Range for MSBK1/2 in TSM
MSBK1/2
Min. Value: 11000
Max. Value: 34000
Differential Range: min. 5500
Malfunctions in the balance chamber can occur if:
• the values are out of limits
• the minimal difference from the detected min. value was not reached
