B. Braun Dialog+ - Water Sub-Rack

7. Spare Parts List 1/2010 7 - 9
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
EP
VEB
VZ
PE
DMV
VVBE
H
WT
NSVB
WAB
6,7
5
2
1
11
13
14
Water Sub-Rack
11
34561242 1 Pressure sensor
11
34773762 10 O-ring 9.25 x 1.78
12
34516069 1 Throttle 0 - 4 bar
13
34517243 1
Tubing connector
∅
7 x 1/8"
stainless steel
14
34560289 1 Solenoid valve 2/2 way
connector/connector (DPP)
