B. Braun Dialog+ - Air Separator Assembly Group

7. Spare Parts List 1/2010 7 - 18
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
7.5.2 Air Separator Assembly Group
4
34560270 1 Solenoid valve 2/2 way
connector/flange (DPP)
4/7
34770852 5 O-ring 11.1 x 1.6
5
3451727B 1 Throttle 0.4 bar
5/6
34570683 10 O-ring 4.47 x 1.78
6
3451664B 1 Throttle 1.3 bar
7
3451916A 5
Tubing connector
∅
8 x 1/8"
plastic
VLA
LA
5
6
DDE
VBP
4
RVFPA
7
VLA
VBP
LA
RVFPA
DDE
4
7
