2.22.6 Fuses
Fuse Voltage
Rated Fuse Value
Fuse Type
Connector
F1
L
(Mains Input)
6.25 A
(6.3 x 32)
X1.1
F2
N
(Mains Input)
6.25 A
(6.3 x 32)
X1.2
F5A
L
(Heater 1, 900 W)
12 A (110/120 V)
6.25 A (230 V)
(6.3 x 32)
X1.6
F5B
L
(Heater 2, 900 W)
12 A (110/120 V)
6.25 A (230 V)
(6.3 x 32)
X1.7
F6
N
(Heater)
20 A (110/120 V)
12 A (230 V)
(6.3 x 32)
X1.5
P4/1
P4/4
P6/1
P11/1
P12/1
F301
+5 VD1 3.15 A (TR5)
P14/6
F302
+5 VD2
5 A (TR5)
P5/10
P10/1
P10/4
F303
+5 VD3
3.15 A (TR5)
P10/7
P7/1
F304
+5 VD4
3.15 A (TR5)
P8/1
F401
+12 VD1
3.15 A (TR5)
P12/2
X100/1
P5/4
P7/4
P8/4
P9/5
P9/6
P10/10
P10/14
F402
+12 VD2 5 A (TR5)
P11/2
P4/7
P5/1
P7/7
P8/7
F403
+12 VD3 1.25 A (TR5)
P12/4
P4/10
P4/13
P5/8
F600
+24 VL 10 A (6.3 x 32)
P12/10
P4/11
P4/14
P5/7
F601
+24 VGB 3.15 A (TR5)
P12/13
P4/12
P4/15
F602
+24 VGD 3.15 A (TR5)
P12/14
Note:
Soldered fuses (e.g. F300 or F500) must not be changed if they are
defective, i.e. the complete SMPS-MC must be exchanged.
