7. Spare Parts List 1/2010 7 - 33
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
7.8.1 Manometer Connection
2
3457058A 5
Manometer connection (white), for PBS/SN
with plastic nut A and
2
3451833A 5
Manometer connection (red), for PA/PBE
safety disc B (pay attention to
2
3451884A 5
Manometer connection (blue), for PV
correct assembly, see left figure)
7.8.2 Heparin Pump
5
3451432B 1 Heparin pump Compact
5
34560785 1 Housing with seal
5a
34514732 1
Syringe holder
5b
34570640 5
Dummy plug
5c
34570667 1
Clamp
5d
34570659 1
Unlocking lever set
A
B
2
HP
5
5a
5b
5c
5d
