3.6.9 Card Reader Read/Write Utilities
The group of read and write utilities for the card reader is used:
•
to read data from a card or diskette and to write them to a USB stick
•
to read data from a USB stick and to write them to a card
•
All card reader utilities are available in a sub-menu.
3.6.9.1 Select Menu of Card Reader
Commands
Select the
09. Select Menu of Card Reader Commands
to open the sub-menu for
the card reader utilities.
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
01. Set System Version Number
02. Set Working Time Counter (WTC)
03. Kill Masterboot Record (Dialog+ Hard Disk)
04. Write Languages (USB Stick
→
Dialog+ Hard Disk)
05. Write Calibration Data (USB Stick
→
Dialog+ Hard Disk)
06. Write System Configuration (USB Stick
→
Dialog+ Hard Disk)
07. Undo Last Written (USB Stick
→
Dialog+ Hard Disk)
08. USB Stick Self Test
09. Select Menu of Card Reader Commands
10. Read System Configuration (Dialog+ Hard Disk
→
USB Stick)
11. Read Calibration Data (Dialog+ Hard Disk
→
USB Stick)
12. Read All Trends (Dialog+ Hard Disk
→
USB Stick)
13. Read Screenshots (Dialog+ Hard Disk
→
USB Stick)
14. Get Error (ErrorDisk) (Dialog+ Hard Disk
→
USB Stick)
BP-
: move cursor up
BP+
: move cursor down
AQ
: exit – see
Important Note EQ
: execute
Important Note:
To prevent the corruption of USB stick, before removing it,
please press
AQ
then follow the instructions on the screen!
1.
Press the
BP
hardware key and move the cursor
down to select the utility:
09. Select Menu of Card Reader Commands
.
2.
Press the
EQ
hardware key to execute the
utility.
