B. Braun Dialog+ - Service Overview in Therapy

4. TSM Service Program 1/2010 4 - 9
BA-TE-DE08C M.KAY Dialog+ SW9xx_SM_Chapter 4-1-1_1-2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
4.4 Service Overview in Therapy
The service overview can be selected in therapy with the Service Key icon. The
second and third page of the service overview can be selected with the service
key icon.
Click the Door icon to jump back to the initial menu.
Water Tank
VVBE: OPENED/CLOSED
NSVB: HIGH/LOW
Degassing
EP: XXXX rpm
VEB: OPEN/CLOSED
PE: XXX mmHg
TSE: XX.X
o
C
TSHE: XX.X
o
C
Heater
HEATER: XX.X %
Air Separator
LAFSO: NO AIR/AIR
LAFSU: NO AIR/AIR
VLA: OPEN/CLOSED
Temperature
TSE: XX.X
o
C
TSBIC: XX.X
o
C
TSD: XX.X
o
C
TSD_S: XX.X
o
C
TSDE: XX.X
o
C
Conductivity
BICLF: X.X mS/cm
ENDLF: XX.X mS/cm
ENDLF_S: XX.X mS/cm
BICP: XX rpm
BICP_S: XX rpm
BIC-Ratio: XX.X
BIC-Ratio_S: XX.X
KP: XX rpm
KP_S: XX rpm
END-Ratio: XX.X
END-Ratio_S: XX.X
Balance Chamber
MSBK1: XXXXX
MSBK2: XXXXX
VEBK1_S: OPEN/CLOSED
VABK1_S: OPEN/CLOSED
VDEBK2_S: OPEN/CLOSED
VDABK2_S: OPEN/CLOSED
VEBK2_S: OPEN/CLOSED
VABK2_S: OPEN/CLOSED
VDEBK1_S: OPEN/CLOSED
VDABK1_S: OPEN/CLOSED
Flow (Dialysate Fluid)
FPE: XXXX rpm
FPA: XXXX rpm
FMD: XXX ml/min
FMD_S XXX ml/min
Valves (Bypass)
VBP: OPEN/CLOSED
VBP_S: OPEN/CLOSED
VDE: OPEN/CLOSED
VDE_S: OPEN/CLOSED
VDA: OPEN/CLOSED
VDA_S: OPEN/CLOSED
Valves (Disinfection)
VZ: OPEN/CLOSED
VD OPEN/CLOSED
VD_S OPEN/CLOSED
Blood Leak
BL: X.XX ‰
BL_S: X.XX ‰
Ultrafiltration
UFP: XX rpm
UFP_S: XX rpm
PDA: XXX mmHg
PDA_S: XXX mmHg
TMP: XXX mmHg
BIC Cartridge Holder
BKUS: OPEN/CLOSED
BKUS_S: OPEN/CLOSED
VVB: OPEN/CLOSED
VBICP: OPEN/CLOSED
VBKO: OPEN/CLOSED
VBKS: OPEN/CLOSED
Valves Online
VBE: OPEN/CLOSED
VBE_S: OPEN/CLOSED
VDFF: OPEN/CLOSED
VDFF_S: OPEN/CLOSED
VSB: OPEN/CLOSED
VSB_S: OPEN/CLOSED
VSAA: OPEN/CLOSED
VSAA_S: OPEN/CLOSED
VSAE: OPEN/CLOSED
VSAE_S: OPEN/CLOSED
Pump Online
OPS: XXXX rpm
OPS_S: XXXX rpm
Subst. Flow (Online)
FMS: XXX ml/min
FMS_S: XXX ml/min
Blood Side (Pressure)
PA: XXX mmHg
PA_S: XXX mmHg
PBE: XXX mmHg
PV: XXX mmHg
PV_S: XXX mmHg
PBS: XXX mmHg
PBS_S: XXX mmHg
Blood Pumps
BPA: XXXX rpm
BPA_S: XXXX rpm
BPV: XXXX rpm
BPV_S: XXXX rpm
Tubing Clamps
SAKA: OPEN/CLOSED
SAKV: OPEN/CLOSED
SAKV_S: OPEN/CLOSED
Air Detector
SAD: NO AIR/AIR
SAD_S: NO AIR/AIR
SAD TIME_S: OK
SAD REF_S: XXXX mV
SAD VOL: XXXX µl
SAD VOL_S: XXXX µl
Heparin
HP: STOP
POSITION: XX.XX mm
Status Self Test
LLC: XXXXX
LLS: XXXXX
LLC/S & TLC Alarm Window LLC Message Window
Fig.: First Page Service Overview in Therapy
Balance Chamber
MSBK1: 32134
MSBK2: 32270
Digit Range for MSBK1/2 in Therapy
MSBK1/2
Min. Value: 10000
Max. Value: 35000
Differential Range: min. 7500
Malfunctions in the balance chamber can occur if:
• the values are out of limits
• the minimal difference from the detected min. value was not reached
