The second page of the service overview can be selected with the Service Key
icon.
Click the Door icon to jump back to the initial menu.
Dialog - Basic
UF Volume
UF NET: XXX ml
UF GROSS: XXX ml
UF GROSS_S: XXX ml
Relay
B24V_S: ON/OFF
D24V_S: ON/OFF
HEATER REL1_S: ON/OFF
HEATER REL2_S: ON/OFF
Couplings
SBS1: COUPLED/UNCOUPLED
SBS2: COUPLED/UNCOUPLED
BIC_SS: COUPLED/UNCOUPLED
K_SS: COUPLED/UNCOUPLED
Red Sensor
RDV: NO BLOOD/BLOOD
OSD Red LED
RIGHT LED_S: ON/OFF
LEFT LED_S: ON/OFF
Loudspeaker
LS PULSE_S: ON/OFF
LS CURRENTS_S: ON/OFF
PD Read By
TLC VER: X.XX
DBI VER: X.XX.X
PD Written By
TLC VER:
DBI VER:
HDF Bag
Substitution Volume
SUBST: X ml
SUBST_S: X ml
SUBST_WV_S: X ml
SUM INF: X ml
ACT INF_S: X ml
INF LEAK_S X ml
Weight
BAG: X g
BAG_S: X g
Flow Detector
UF_FLOW: FLOW/NO FLOW
Air Detector
SUBAD: AIR/NO AIR
Level Regulation
Pump (Level Regulation)
PPR: START/STOP
Valves (Level Regulation)
VBT_S: OPEN/CLOSED
VPA_S: OPEN/CLOSED
VPV_S: OPEN/CLOSED
VPE_S: OPEN/CLOSED
VPD_S: OPEN/CLOSED
HDF/HF Online
HDF/HF Volume
HDF/HF_V: X.X l
HDF/HF_V_S: X.X l
BOLUS_VOL: X ml
BOLUS_VOL_S: X ml
Reed Sensor
PSAUS: OPEN/CLOSED
PSABF: OPEN/CLOSED
FDFS: OPEN/CLOSED
FHDFS: OPEN/CLOSED
Remaining Filter Time
DF: XXX h
HDF: XXX h
Remaining Dialysis
DF: XXX
HDF: XXX
Others
SMPS Battery
Batt. enabled: YES/NO
Self Test: NOT OK/OK
bioLogic RR
Algorithm ID: X
Algorithm SW: V X.XX
GL Curves: X
Crit-Line
Patient ID: X
Station ID: X
Start Date: XX X.XX, XXXXX
Start Time: XX:XX:XX
Actual Date: XX X.XX, XXXXX
Actual Time: XX:XX:XX
HCT Start: X.XX %
Unit ID: X
CL Data error: XXXX
CL Error Count: X
Preventive Service
Warning Enabled YES/NO
Date of Last Service NONE
WTC of Last Service NONE
Status of Machine XXX%
WTC
WTC Actual XXXXX h
LLC ALARM:
0000 0000 0000 0000 0000 0000
MESSAGE:
0000 0000 0000 0000 0000 0000
LLS ALARM:
0000 0000 0000 0000 0000 0000
FREE M:
XXXX/XXX of XXXXX kB S: XX/XX MB
LLC/S & TLC Alarm Window LLC Message Window
Fig.: Second Page Service Overview in Therapy
