B. Braun Dialog+ - Read Card Image

3. Repair Instructions 1/2010 3 - 75
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
3.6.9.2 Read Card Image
BlueCat
Removable Disk (X: - FSU USB Stick)
DISKTYPE
USER
05_Write_Calibration_Data
04_Write_Languages
06_Write_System_Configuration
09_Card_01_Read_Card_Image
This utility reads card image from the card as a
compressed
scard.img.zip
file to the FSU USB stick.
Read Card Image
USB:\USER\09_Card_01_Read_Card_Image\{YYYY-
MM-DD.hh.mm.ss}\scard.img.zip
Example:
USB:\USER\09_Card_01_Read_Card_Image\{2007-
08-30.15.34.12}\
scard.img.zip
YYYY: Year 2007
MM : 08 month August
DD : 30 Thursday
hh : 15 hours
mm : 34 minutes
ss : 12 seconds
Field Service Utilities V2.00 - Set000
CRC = XXXX - OK
01. Read Card Image (Card
→
USB Stick)
02. Write Card Image (USB Stick
→
Card)
03. Read Patient Diskette (Diskette
→
USB Stick)
04. Write Patient Diskette to Card (USB Stick
→
Card)
05. Read Patient Card (Card
→
USB Stick)
06. Write Patient Card (USB Stick
→
Card)
07. Remove All Patient Data
BP-
: move cursor up
BP+
: move cursor down
AQ
: back to previous menu
EQ
:
execute
1.
Press the
BP
hardware key, move cursor down
and select
09. Select Menu of Card Reader
Commands
in the main menu.
2.
Press the
EQ
hardware key to execute the
utility.
•
Yes, card image is written to USB stick
3.
Press the
AQ
hardware key to skip to the
previous menu.
•
No, card image is not written to USB stick
Reading card image - ............
End of Read Card Image
Press the
‘AQ’
key to continue . . .
