B. Braun Dialog+ - DF Sub-Rack

7. Spare Parts List 1/2010 7 - 11
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
FPE
FPA
1
2
3
RVB
BICLF
ENDLF
RVK
TSDS
RVFPE
BICP
UFP
KP
7.4 DF Sub-Rack
1
- - Gear pumps
see separate figure for
single parts, paragraph 7.4.1
2
- - DF block
see separate figure for
single parts, paragraph 7.4.1
3
- - Piston pumps
see separate figure for
single parts, paragraph 7.4.2
