3.3.3 EEPROM
Configuration
Switch mode power supply microcontroller SMPS-MC with and without battery
Test Code
25
Repeats Until Error Message
1
ID Error Message
1154:
SMPS-EEPROM defective
Reaction to the Test Result in Preparation
Test is not performed at present
•
Answer from SMPS-MC is
OK
because the EEPROM is not used at present
LLC Test
Code
LLC Test Steps LLS Test Steps LLS Test
Code
1.
Prerequisites for Test:
2.
Test code = 25 to LLS Test code = 25 back to LLC
3.
2510x Switch-off of VGD and VGB 25001
4.
Wait for D24OFF and B24OFF
(Timeout 15 s)
5.
Set set point for heater to self test code #113
6.
2520x Wait for feedback of test result via BIOS (timeout 15 s)
7.
2530x Set set point of heater to 0
8.
2599x Completed VGD ON
VGB ON
3.3.4 Buzzer Test via LLS
Configuration
Switch mode power supply microcontroller SMPS-MC with and without battery
Test Code
28
Repeats Until Error Message
3
ID Error Message
1145:
Self test error SMPS buzzer test
Reaction to the Test Result in Preparation
Error: buzzer defective
•
Information text and
therapy possible
OK:
•
Therapy possible
LLC Test
Code
LLC Test Steps LLS Test Steps LLS Test
Code
1.
Prerequisites for Test:
none
2.
Test code = 10 to LLS Test code = 10 back to LLC
3.
2810x Switch-off of VGD and VGB 28001
4.
Wait for D24OFF and B24OFF
(Timeout 15 s)
5.
Set set point for heater to self test code #115
6.
Activate buzzer after approx. 1 s for 250 ms 28003
7.
2820x Wait for feedback of test result via BIOS (timeout 15 s)
8.
2830x Set set point of heater to 0
9.
2899x Completed VGD ON
VGB ON
