B. Braun Dialog+ - Calibration Degassing Temperature Sensor Tse;Heater Inlet Temperature Sensor TSHE

4. TSM Service Program 1/2010 4 - 128
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
4.8.3.7 Calibration Degassing Temperature Sensor TSE/
Heater Inlet Temperature Sensor TSHE
Prior to Calibration
• Position the heater inlet temperature sensor TSHE next to TSE (see figure
redirect heater inlet temperature sensor TSHE, next page)
• Use calibrated measurement instrument
• Wait until Dialog has reached working temperature
The degassing temperature sensor TSE and the heater inlet temperature sensor
TSHE are calibrated together. The following calibration points are used:
TSE / TSHE: 30 °C, 40 °C, 85 °C
EK
DMV
VVBE
TSE
PE
TSHE
VVB*
VBKO*
DBK*
T
A
D
T
RVBO*
VBKS
TSBI
C
VBICP*
SKBS
RVDA
VLA
H
NSVB
VB
WT
FEP
WA B
EP
VEB
TSH
T
8
. ..
EK
DMV
VVBE
PE
T
SHE
T
SHE
V
VB*
V
BKO*
DBK*
T
A
D
T
T
RVBO*
VBKS
H
NSVB
V
B
WT
FEP
WB
EP
TSH
T
8
Measurement
Instrument
SKBS
C
mS/cm
o
ml/min
VEB
TSE
Fig.: Temperature Circulation Fig.: Loop-In Point and TSHE in Line with TSE for Calibration
EP
RVDA
WAB
H
WT
VEB
KP/BICP
FEP
TSE
NSVB
T
SHE
DBK
EP
RVDA
H
WT
VEB
KP/BICP
FEP
TSE
NSVB
C
mS/cm
o
ml/min
Measurement
Sensor
Keep tubings as short
as possible
Measurement
Instrument
WAB
DBK
TSHE
Fig.: Original Tubing Water Sub-Rack for TSE/TSHE Fig.: Water Sub-Rack with TSHE in Line with TSE for Calibration
