3.6.6 Kill Masterboot Record
The Undo Last Written utility can not be used for restoring.
The utility deletes the contents of the masterboot record (first sector filled with
0x00) of the hard disk drive (CFC) of the Dialog+. This utility is typically used
after replacing a hard disk drive (CFC) against a not empty CFC.
All data on the hard disk drive (CFC) is lost.
Do not switch off the machine immediately after using the
Kill Masterboot
Record
utility. You must wait for the synchronisation between the
operating system and CFC (until the main menu appears).
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
01. Set System Version Number
02. Set Working Time Counter (WTC)
03. Kill Masterboot Record (Dialog+ Hard Disk)
04. Write Languages (USB Stick
→
Dialog+ Hard Disk)
05. Write Calibration Data (USB Stick
→
Dialog+ Hard Disk)
06. Write System Configuration (USB Stick
→
Dialog+ Hard Disk)
07. Undo Last Written (USB Stick
→
Dialog+ Hard Disk)
08. USB Stick Self Test
09. Select Menu of Card Reader Commands
10. Read System Configuration (Dialog+ Hard Disk
→
USB Stick)
11. Read Calibration Data (Dialog+ Hard Disk
→
USB Stick)
12. Read All Trends (Dialog+ Hard Disk
→
USB Stick)
13. Read Screenshots (Dialog+ Hard Disk
→
USB Stick)
14. Get Error (ErrorDisk) (Dialog+ Hard Disk
→
USB Stick)
BP-
: move cursor up
BP+
: move cursor down
AQ
: exit – see
Important Note EQ
: execute
Important Note:
To prevent the corruption of USB stick, before removing it,
please press
AQ
then follow the instructions on the screen!
1.
Press
BP
and move the cursor down to select
the utility.
2.
Press
EQ
to execute the utility.
Field Service Utilities V2.00 - SetMST
CRC = XXXX - OK
Kill Masterboot Record (Dialog+ Hard Disk)
This command destroys ALL DATA on the hard disk of Dialog+.
Are you sure?
AQ
: no
EQ
: yes
An input screen opens to confirm a deletion of the MBR
of the
Masterboot Record
with the following hardware
keys:
AQ
: exit from the utility
EQ
: renewed query for confirmation
Press
EQ
if you are sure.
3.
Press
AQ
if you do not want to delete the
masterboot record.
