B. Braun Dialog+ - Safety Air Detector SAD

7. Spare Parts List 1/2010 7 - 35
Pos. Art. No. Qty. Description Comments
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 7_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
7.8.4 Safety Air Detector SAD
14
3456005C 1 SAD version 3 with
red detector
SAD with board; do not tamper,
exchange only complete
If cover for SAD is present: a ball head allen key 2.5/3 is
required for bottom screw behind rotary magnet.
14
SAD
A
B
SAKA
SAKV-SG
