4. TSM Service Program 1/2010 4 - 160
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
4.8.3.20 Calibration Inlet Flow Pump
Nonreturn Valve RVFPE
You can calibrate the inlet flow pump nonreturn valve RVFPE.
Fig.: Calibration RVFPE/Loop-In Point
Fig.: UF Sub-Rack with FBK1
Fig.: DF Sub-Rack with RVFPE
FBK1
KP UFP
RVFPE
Loop-In Point
for Calibration
