B. Braun Dialog+ - Page 330

4. TSM Service Program 1/2010 4 - 161
BA-TE-DE08W M.KAY Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd B. Braun Avitum AG
Dialog
+
SW 9.xx
• Manometer 0 to 4 bar (art. no. 7701357 or equivalent)
• Flow meter (art. no. 770085A or equivalent)
• Allen key 3 mm
• Size 7 spanner
Please ensure that the manometer and connection tubing are at the same
level as the nonreturn valve during calibration.
1. Connect manometer and flow meter between flow pump FPE and FBK1.
2. Select Test 1.20 Water Part (Overview) in TSM.
3. Increase slowly the speed of FPA, until a flow of 500 ml/min is reached.
4. Set temperature TSD to 37
o
C and wait until temperature is reached.
5. Clamp tubing between manometer and FBK1.
6. Loosen lock nut on RVFPE adjustment screw.
7. Set a pressure of 975 mmHg (1300 mbar) with the adjustment screw of
RVFPE.
• 975 mmHg ±37 mmHg
• 1300 mbar ±50 mbar
8. Tighten lock nut again.
9. Remove manometer and flow meter.
