B. Braun Dialog+ - Tubing Diagram DF Sub-Rack

6. Flow, Wiring and Tubing Diagrams
1/2010
BA-TE-DE08C M.KAY -
Dialog+ SW9xx_sm_Chapter 6_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
6-15
Dialog
+
SW 9.xx
6.3.3 Tubing Diagram DF Sub-Rack
from WA Block
Silicone
Tubing
2.9x3
Silicone
Tubing
2.9x3
Silicone
Tubing
6x3
Silicone
Tubing
6x3
Silicone
Tubing
6x3
Silicone
Tubing
6x3
Silicone
Tubing
6x3
Silicone
Tubing
6x3
Return
Valve
Silicone
Tubing
2.9x3
Y-Tubing
Connector
8 mm
Y-Tubing
Connector
8 mm
Silicone
Tubing
5x3
SNP6
SNP4
T Reduction
from WA Block
to TSHE
(WA Block)
from LA to FBK1 (UF)
to T Reduction
(UF Sub-Rack)
T Reduction
on UF Sub-Rack
from
WA Block
to BIC
Suction Rod
to Concentrate
Suction Rod
to TSHE/VEB
(WA Block)
to LA (UF)
SNP6
SNP1.5 SNP1.5
SNP4
DF Sub-Rack
DF Sub-Rack
DF Sub-Rack
FPA
FPE
KP
UFP
BICP
