B. Braun Dialog+ - Write Card Image

3. Repair Instructions 1/2010 3 - 76
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
Dialog
+
SW 9.xx
3.6.9.3 Write Card Image
BlueCat
Removable Disk (X: - FSU USB Stick)
DISKTYPE
USER
05_Write_Calibration_Data
04_Write_Languages
06_Write_System_Configuration
09_Card_01_Read_Card_Image
09_Card_02_Write_Card_Image
DEFAULT
This utility writes card images from the USB stick as a
compressed
scard.img.zip
file to the card.
If file is not on FSU USB stick
Copy from the PC the compressed
scard.img.zip
file
from the card image to the following USER
subdirectory:
USB:\USER\09_Card_02_Write_Card_Image\DEFAULT\
scard.img.zip
Note:
This utility can not be used to copy the
bioLogic RR activation card.
The process is aborted with the following
message:
ABPS (bioLogic RR) Activation Card Image
can not be written to card.
Field Service Utilities V2.00 - Set000
CRC = XXXX - OK
01. Read Card Image (Card
→
USB Stick)
02. Write Card Image (USB Stick
→
Card)
03. Read Patient Diskette (Diskette
→
USB Stick)
04. Write Patient Diskette to Card (USB Stick
→
Card)
05. Read Patient Card (Card
→
USB Stick)
06. Write Patient Card (USB Stick
→
Card)
07. Remove All Patient Data
BP-
: move cursor up
BP+
: move cursor down
AQ
: back to previous menu
EQ
:
execute
1.
Press the
BP
hardware key, move cursor down
and select
09. Select Menu of Card Reader
Commands
in the main menu.
2.
Press the
BP
hardware key and move the cursor
down to select the utility.
3.
Press the
EQ
hardware key to execute the
utility.
•
Yes, card image is written to card
4. Press the AQ
hardware key to skip to the
previous menu.
•
No, card image is not written to card
Field Service Utilities V2.00 - Set000
CRC = XXXX - OK
Write Card Image (USB stick
→
Card)
................
End of Write Card Image
Press the
‘AQ’
key to continue . . .
