B. Braun Dialog+ - Tubing Diagram BIC Cartridge Holder

6. Flow, Wiring and Tubing Diagrams
1/2010
BA-TE-DE08C M.KAY -
Dialog+ SW9xx_sm_Chapter 6_1-2010.doc/pdf <100329> yymmdd
B. Braun Avitum AG
6-17
Dialog
+
SW 9.xx
6.3.5 Tubing Diagram BIC Cartridge Holder
Silicone
Tubing
6x3
Silicone Tubing 6x3
Silicone Tubing 6x3
Silicone
Tubing
5x3
Silicone Tubing 5x3
Silicone Tubing 5x3
Silicone Tubing 5x3
Silicone Tubing 2.9x3
Silicone Tubing 2.9x3
Silicone Tubing 2.9x3
Silicone Tubing
2.9x3
Silicone
Tubing
2.9x3
Silicone Tubing 2x3
Silicone Tubing 5x3
Silicone Tubing 5x3
Silicone
Tubing
5x3
Silicone Tubing 5x3
DBK
TSE
VBKS
VBICP
RVDA
VBKO
VVB
RVB
Disposable
Filter
SNP1.5
SNP6
SNP6
SNP6
SNP1.5
SNP4
SNP6
SNP4
Reduction Piece
Y-Tubing Connector 4-6-4
Y-Tubing
Connector
8 mm
DBK
DF Block
Water
Block
BICP
DF Sub-Rack
Water Sub-Rack
BIC Cartridge Holder
Water Sub-Rack
BKUS
VBKS
VBICP
VBKO
VVB
VZ
VEB
T Reduction
